Lindemann Musicbook Combo

Measurement conditions: 22° C, 230 V mains voltage
Power supply: 90 – 240 V, 50 – 60 Hz
Power consumption: 0.5 W standby, 16 W operation, 160 W max
Dimensions: 280 x 220 x 63 mm (W x D x H)
Weight: 3.0 kg

D/A Converter

Resolution: 768 kHz / 32 bit and DSD 512
Dynamic range: > 125 dB
THD & Noise: < 0.001% (@ 0 dB FS)
Master clock: Ultra-low-jitter MEMS femto clock
Re-sampling: 180 dB dynamic range and 32-bit resolution, bit-perfect or DSD
Jitter suppression (re-sampling): > 60 dB
Converter architecture: AK4493 DAC, AK4137 re-sampler

Network Player

Ethernet: 100 Mbit/s
Wi-Fi: Dual-band 802.11a/b/g/n/ac, WPS support
Bluetooth: 4.2, A2DP, Codecs: SBC/AAC
USB: High-speed host interface for hard drives, USB sticks, CD-ROM drives, max output current: 1.5 A
Supported codecs: WAV, FLAC, AIFF, ALAC, MP3, AAC, Ogg Vorbis, WMA, DSD
UPnP and DLNA support
PCM resolution: 44.1 kHz to 384 kHz, 24 bit (Wi-Fi up to 192 kHz)
DSD resolution: DSD 64 to DSD 256 (Wi-Fi up to DSD 128)
Gapless playback
Streaming services: TIDAL (Connect), Qobuz (Connect), Deezer, HighResAudio, Spotify Connect
Internet radio and podcast
Roon Ready

Analog Preamplifier

Inputs: Two analog line inputs with 50 kOhm input impedance. Max input voltage: 2.5 V.
MM input for turntables. MM specs: 47 kOhm / 150 pF / 40 dB gain
Outputs: One line output (RCA). Output impedance: 100 Ohm. Max output voltage: 1 V
Volume control range: 0 to 80 dB in 1 dB steps
Balance control: + / – 6 dB in 1 dB steps
Frequency response: 1 – 100 kHz (-3 dB)
THD & Noise: < 0.001% @ 3 V output

Power Amplifier

Power output: 2 x 130 W @ 4 Ohm, 2 x 70 W @ 8 Ohm
THD & Noise: < 0.003% @ 10 W / 4 Ohm
Damping factor: > 500

Headphone Amplifier

Headphone jack: 6.35 mm (1/4″) stereo
Gain: switchable 0 dB / 12 dB
Recommended headphone impedance: 16 – 200 Ohm
Damping factor: > 100
